In-system programming (ISP) / in-circuit serial programming (ICSP)
pinout:
- Základní údaje
AVRDUDE:
read signature:
avrdude -p m328p -v -B 10 -c USBasp -U signature:r:-:h
read fuses:
avrdude -p m328p -v -B 10 -c USBasp -U lfuse:r:-:h -U hfuse:r:-:h -U efuse:r:-:h
| Low | High | Extended | BOD | avrdude -p m328p -v -B 10 -c USBasp |
| 0xFF | 0xDA | 0xFE | 1,8 V | -U lfuse:w:0xff:m -U hfuse:w:0xda:m -U efuse:w:0xfe:m |
| 0xFF | 0xDA | 0xFD | 2,7 V | -U lfuse:w:0xff:m -U hfuse:w:0xda:m -U efuse:w:0xfd:m |
| 0xFF | 0xDA | 0xFF | DISABLE | -U lfuse:w:0xff:m -U hfuse:w:0xda:m -U efuse:w:0xff:m |
write fuses (default for Arduino Duemilanove, Pro Mini 8 - 16 MHz, 2,7 V BOD):
avrdude -p m328p -v -B 10 -c USBasp -U lfuse:w:0xff:m -U hfuse:w:0xda:m -U efuse:w:0xfd:m
write fuse (1,8 V BOD):
avrdude -p m328p -v -B 10 -c USBasp -U efuse:w:0xfe:m
write bootloader:
avrdude -p m328p -c USBasp -e -U flash:w:ATmegaBOOT_168_atmega328.hex:i
avrdude -p m328p -c USBasp -e -U flash:w:optiboot_atmega328.hex:i
avrdude -p m328p -c USBasp -e -U flash:w:ATmegaBOOT_168_atmega328_pro_8MHz.hex:i
read flash:
avrdude -p m328p -c USBasp -U flash:r:-:i
avrdude -p m328p -P usb -c USBasp -U flash:r:flash.hex:i
read eeprom:
avrdude -p m328p -v -c USBasp -U eeprom:r:-:i
avrdude -p m328p -v -c USBasp -U eeprom:r:eeprom.hex:i
erase flash:
avrdude -p m328p -c USBasp -e
HEX file checksum calculator
Firmware for microcontrollers are often stored in Intel HEX files. For testing and debugging sometimes it is necessary to change some values directly in the HEX file. The Intel HEX file format is easy to read and to modify except the checksum.
Analyse HEX file line
Please enter one line of HEX file to analyze it, to calculate and verify the checksum. If you don't know the checksum, you can omit it.
- Základní údaje
Arduino Pro Micro a podobné klony, které mají čip ATmega32U4, s integrovaným řadičem v čipu RX/TX - USB, se při inicializaci seriového protu v programu, dojde k chybě a port se nepříhlásí do Windows.
